Introduction

Imagine you have a VPS running Home Assistant, Nextcloud, or a self-hosted blog. You want to access it from outside, but:

• Your ISP doesn’t provide a public IPv4 address;
• You don’t want to configure port forwarding on your router;
• You’d rather not deal with SSL certificates;
• Exposing SSH and web ports directly worries you.

Cloudflare Tunnels was built for exactly this. It installs a lightweight tunnel daemon (cloudflared) on your server that encrypts and forwards your services through Cloudflare’s global edge network. No inbound ports need to be opened, and no public IP is required.

This guide walks you through setting up a complete Cloudflare Tunnels-based VPS exposure solution, working seamlessly with Docker.

How It Works

[Browser] ←HTTPS→ [Cloudflare Edge] ←TLS→ [cloudflared Tunnel] ←HTTP→ [Your VPS Service]

1. You run cloudflared on your VPS, which proactively establishes TCP connections to Cloudflare’s edge
2. Since the connection is outbound-only, your firewall doesn’t need to allow any incoming ports
3. When a user sends an HTTPS request to Cloudflare, it’s forwarded through the tunnel to your VPS
4. Both ends of the tunnel are encrypted, ensuring data security

Key Advantages

Step 1: Register Cloudflare & Add Your Domain

1. Visit cloudflare.com and create an account
2. Add your domain (you can use an existing domain or sign up for a free one)
3. Point your domain’s NS records to the NS servers Cloudflare provides
4. Wait for DNS to propagate (usually minutes to a few hours)

💡 Cost-saving tip: If you don’t have a domain yet, Cloudflare occasionally offers free domain registration promotions. Alternatively, check out Freenom for free .tk / .ml domains (though paid domains offer better reliability).

Step 2: Install cloudflared

Method 1: Using Docker (Recommended)

# Create config directory
mkdir -p ~/cloudflared/config
cd ~/cloudflared

# Pull the image
docker pull cloudflare/cloudflared:latest

Method 2: Install Binary Directly

# Ubuntu/Debian
wget https://github.com/cloudflare/cloudflared/releases/latest/download/cloudflared-linux-amd64
chmod +x cloudflared-linux-amd64
sudo mv cloudflared-linux-amd64 /usr/local/bin/cloudflared

# Verify installation
cloudflared --version

Step 3: Create Tunnel & Authenticate

Using Access Tunnel (Simplest, for personal use)

# Run authentication command
cloudflared tunnel login

This opens a browser window to Cloudflare’s authentication page. Select your domain account, authorize, and you’re done. The certificate is saved to ~/.cloudflared/cert.pem.

Using Tunnel CID (For teams / production)

# Create a tunnel
cloudflared tunnel create my-vps-tunnel

# Output looks like:
# Tunnel credentials saved to /home/user/.cloudflared/<tunnel-id>.json
# Tunnel my-vps-tunnel (xxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx) created

Note the Tunnel ID for later steps.

Step 4: Configure Routing Rules

Method 1: YAML Configuration File

Create ~/cloudflared/config/config.yml:

tunnel: <YOUR_TUNNEL_ID>
credentials-file: /home/<your-username>/.cloudflared/<TUNNEL_ID>.json

ingress:
  # Main domain → Blog
  - hostname: blog.yourdomain.com
    service: http://localhost:8080

  # Nextcloud
  - hostname: files.yourdomain.com
    service: http://localhost:8081

  # Home Assistant
  - hostname: home.yourdomain.com
    service: http://localhost:8123

  # Default 404
  - service: http_status:404

Method 2: Docker Compose Integration

Create ~/cloudflared/docker-compose.yml:

version: "3.8"

services:
  cloudflared:
    image: cloudflare/cloudflared:latest
    container_name: cloudflared
    restart: unless-stopped
    command: tunnel --no-autoupdate run
    volumes:
      - ./config:/etc/cloudflared:ro
    environment:
      - TUNNEL_TOKEN=<YOUR_TUNNEL_TOKEN>  # Omit if using login method

  # Example: Blog service
  blog:
    image: ghcr.io/go-hugo/hugo:extended
    container_name: hugo-blog
    restart: unless-stopped
    ports:
      - "8080:80"
    volumes:
      - ./blog:/src

  # Example: Nextcloud
  nextcloud:
    image: nextcloud:apache
    container_name: nextcloud
    restart: unless-stopped
    ports:
      - "8081:80"
    volumes:
      - nextcloud_data:/var/www/html
    environment:
      - MYSQL_DATABASE=nextcloud
      - MYSQL_USER=nextcloud
      - MYSQL_PASSWORD=secure_password_here
      - MYSQL_HOST=db

  db:
    image: mysql:8
    container_name: nextcloud-db
    restart: unless-stopped
    volumes:
      - mysql_data:/var/lib/mysql
    environment:
      - MYSQL_ROOT_PASSWORD=root_secure_password
      - MYSQL_DATABASE=nextcloud
      - MYSQL_USER=nextcloud
      - MYSQL_PASSWORD=secure_password_here

volumes:
  nextcloud_data:
  mysql_data:

Step 5: Start the Tunnel

Using systemd (Recommended for production)

# Create service file
sudo tee /etc/systemd/system/cloudflared.service > /dev/null << 'EOF'
[Unit]
Description=Cloudflare Tunnel
After=network-online.target
Wants=network-online.target

[Service]
Type=notify
ExecStart=/usr/local/bin/cloudflared tunnel --config /home/<username>/.cloudflared/config.yml run
Restart=on-failure
RestartSec=5
LimitNOFILE=infinity

[Install]
WantedBy=multi-user.target
EOF

# Start and enable on boot
sudo systemctl daemon-reload
sudo systemctl enable --now cloudflared

# Check status
sudo systemctl status cloudflared

# View tunnel logs
cloudflared tunnel route dns <tunnel-name> <subdomain>.yourdomain.com

Using Docker Compose

cd ~/cloudflared
docker compose up -d

Step 6: DNS Routing Configuration

Associate subdomains with your tunnel:

# Add DNS records (using TUNNEL_ID)
cloudflared tunnel route dns my-vps-tunnel blog.yourdomain.com
cloudflared tunnel route dns my-vps-tunnel files.yourdomain.com
cloudflared tunnel route dns my-vps-tunnel home.yourdomain.com

# Verify DNS records
cloudflared tunnel info my-vps-tunnel

After this, visiting https://blog.yourdomain.com in your browser will show your service.

Step 7 (Optional): Cloudflare Access Authentication

If you want to restrict access to certain services (e.g., Home Assistant), enable Cloudflare Access:

# In Cloudflare Dashboard:
# 1. Go to Zero Trust → Access → Applications
# 2. Click "Add an application"
# 3. Select "Self-hosted"
# 4. Set Domain: home.yourdomain.com
# 5. Set Auth Domain: yourdomain.com
# 6. Choose verification method (Google/GitHub/Email, etc.)

After enabling, visiting home.yourdomain.com will redirect to a login page. Only authenticated users can access the service.

Configure Access Policy via CLI

# Use Cloudflare API Token for configuration
curl -X POST "https://api.cloudflare.com/client/v4/accounts/<ACCOUNT_ID>/access/services/gateway/service_report" \
  -H "Authorization: Bearer <API_TOKEN>" \
  -H "Content-Type: application/json" \
  -d '{
    "enabled": true
  }'

Troubleshooting

1. Tunnel Connection Fails

# Check cloudflared logs
sudo journalctl -u cloudflared -f

# Common causes:
# - cert.pem expired (re-run cloudflared tunnel login)
# - Wrong TUNNEL_ID (check config file)
# - Network issues (ensure VPS can reach 200.0.0.0/4)

2. Service Returns 502 Bad Gateway

• Confirm your local service is running: curl http://localhost:8080
• Verify the port numbers in config.yml are correct
• Check that the service listens on 0.0.0.0, not just 127.0.0.1

3. SSL Certificate Issues

Cloudflare Tunnels use Cloudflare’s wildcard certificates by default. If your browser shows an unsafe certificate warning:

• Ensure the domain is properly added to Cloudflare
• Set TLS mode to Full (Cloudflare Dashboard → DNS → SSL/TLS)
• Clear browser cache and retry

4. Bandwidth Limits

Free Cloudflare Tunnels have a 100 GB/month egress limit. Usually sufficient for personal use. If exceeded:

• Monitor usage: Cloudflare Dashboard → Analytics
• Consider upgrading to Pro plan ($20/month)
• Enable cache rules for high-traffic services

Comparison with Alternatives

💡 Best practice: Recommended combo for self-hosting—Cloudflare Tunnels (public exposure) + Tailscale (internal management). Route public services through Tunnels, SSH management through Tailscale. Each excels at what it does.

Summary

Cloudflare Tunnels is currently the best VPS exposure solution for self-hosting enthusiasts:

• ✅ Zero ports opened — significantly improved security
• ✅ Automatic HTTPS — no manual certificate management
• ✅ DDoS protection — backed by Cloudflare’s global network
• ✅ Free to use — 100GB/month egress sufficient for personal use
• ✅ Access integration — easily add authentication

For setting up blogs, Nextcloud, Home Assistant, and other self-hosted services, Cloudflare Tunnels is the most hassle-free option. Paired with Docker, the entire deployment takes less than 10 minutes.

Get started today and put your services on the internet safely!
