mkdir -p /opt/net-discovery
vim /opt/net-discovery/collect.sh

#!/bin/bash
# /opt/net-discovery/collect.sh — Full network state collection
set -euo pipefail

TIMESTAMP=$(date '+%Y-%m-%d %H:%M:%S')
OUT_DIR="/tmp/net-discovery"
mkdir -p "$OUT_DIR"

echo "=== Collection Time: $TIMESTAMP ===" > "$OUT_DIR/timestamp.txt"

# 1. Listening ports (TCP/UDP)
echo "=== Listening Ports ===" > "$OUT_DIR/listening_ports.txt"
ss -tulnp 2>/dev/null >> "$OUT_DIR/listening_ports.txt" || true

# 2. Active connections
echo "=== Active Connections ===" > "$OUT_DIR/active_connections.txt"
ss -tnp 2>/dev/null | head -200 >> "$OUT_DIR/active_connections.txt" || true

# 3. Docker network info
echo "=== Docker Networks ===" > "$OUT_DIR/docker_networks.txt"
docker network ls 2>/dev/null >> "$OUT_DIR/docker_networks.txt" || true
docker network inspect "$(docker network ls --format '{{.Name}}' 2>/dev/null | tr '\n' ',' | sed 's/,$//')" \
  > "$OUT_DIR/docker_network_inspect.json" 2>/dev/null || true

# 4. Docker container port mappings
echo "=== Docker Port Mappings ===" > "$OUT_DIR/docker_ports.txt"
docker ps --format '{{.Names}}\t{{.Ports}}\t{{.Status}}' 2>/dev/null \
  >> "$OUT_DIR/docker_ports.txt" || true

# 5. Firewall rules
echo "=== iptables Rules ===" > "$OUT_DIR/iptables_rules.txt"
iptables -L -n -v 2>/dev/null >> "$OUT_DIR/iptables_rules.txt" || true
iptables -t nat -L -n -v 2>/dev/null >> "$OUT_DIR/iptables_rules.txt" || true

# 6. Process network behavior
echo "=== Process Network Connections ===" > "$OUT_DIR/process_network.txt"
ss -tnp 2>/dev/null >> "$OUT_DIR/process_network.txt" || true

# 7. Host network interfaces
echo "=== Network Interfaces ===" > "$OUT_DIR/interfaces.txt"
ip addr show 2>/dev/null >> "$OUT_DIR/interfaces.txt" || true
ip route 2>/dev/null >> "$OUT_DIR/routes.txt" || true

echo "[$TIMESTAMP] Collection complete → $OUT_DIR"

chmod +x /opt/net-discovery/collect.sh
# Collect every 15 minutes
(crontab -l 2>/dev/null; echo "*/15 * * * * /opt/net-discovery/collect.sh") | crontab -

vim /opt/net-discovery/analyze.py

#!/usr/bin/env python3
"""
AI Network Topology Discovery & Security Scoring Engine
Reads collected data → LLM reasoning → outputs topology map + security policy recommendations
"""
import json
import subprocess
import time
from pathlib import Path
from datetime import datetime

DATA_DIR = Path("/tmp/net-discovery")
OLLAMA_URL = "http://localhost:11434"
MODEL = "qwen2.5:7b"
BASELINE_DIR = Path("/var/db/net-baseline")
BASELINE_DIR.mkdir(parents=True, exist_ok=True)


def read_all_data() -> str:
    """Read all collected files into a single context"""
    parts = []
    for f in sorted(DATA_DIR.glob("*.txt")):
        if f.name == "timestamp.txt":
            continue
        if f.exists():
            parts.append(f"### {f.stem.upper()}\n{f.read_text()}")
    for f in DATA_DIR.glob("*.json"):
        if f.exists():
            parts.append(f"### {f.stem.upper()}\n{f.read_text()[:8000]}")
    return "\n\n".join(parts)


def build_prompt(raw_data: str) -> str:
    return f"""You are a professional network security engineer and VPS operations expert. Analyze the following network collection data and complete three tasks:

## Task 1: Build Service Topology
Identify all network services (containers/processes) and infer their dependency relationships.
Format: SERVICE_A --> SERVICE_B (protocol:port)

## Task 2: Risk Assessment
Rate each exposed port (HIGH/MEDIUM/LOW) with reasoning. Pay special attention to:
- Database ports exposed to public internet
- SSH exposed without IP restriction
- Unauthenticated admin panels
- Unencrypted HTTP traffic

## Task 3: Least-Privilege Firewall Recommendations
Generate iptables rules for each service following the principle of least privilege.

Network collection data:
{raw_data}

Output your analysis in the following JSON format only (no other content):
{{
  "topology": [
    {{"from": "service_name", "to": "service_name", "protocol": "tcp", "port": 5432, "justification": "reason"}}
  ],
  "exposed_services": [
    {{"service": "name", "port": port_number, "binding": "0.0.0.0 or 127.0.0.1", "risk": "HIGH/MEDIUM/LOW", "reason": "explanation"}}
  ],
  "iptables_rules": [
    {{"chain": "INPUT/DOCKER", "rule": "full iptables command"}}
  ],
  "summary": "One-paragraph summary of current network security status",
  "recommendations": ["recommendation1", "recommendation2"]
}}
"""


def call_llm(prompt: str) -> dict:
    """Call Ollama local LLM"""
    payload = json.dumps({
        "model": MODEL,
        "prompt": prompt,
        "stream": False,
        "options": {"temperature": 0.1, "num_ctx": 32768}
    })
    try:
        result = subprocess.run(
            ["curl", "-s", f"{OLLAMA_URL}/api/generate", "-d", payload],
            capture_output=True, text=True, timeout=180
        )
        response = json.loads(result.stdout)
        text = response.get("response", "{}")
        if "```json" in text:
            text = text.split("```json")[1].split("```")[0]
        elif "```" in text:
            text = text.split("```")[1].split("```")[0]
        return json.loads(text.strip())
    except Exception as e:
        return {"error": str(e), "topology": [], "exposed_services": [], "recommendations": []}


def drift_detection(current: dict) -> list:
    """Compare with baseline to detect configuration drift"""
    baseline_file = BASELINE_DIR / "latest.json"
    if not baseline_file.exists():
        baseline_file.write_text(json.dumps(current, ensure_ascii=False, indent=2))
        return [{"type": "baseline_created", "message": "Initial network baseline created"}]

    previous = json.loads(baseline_file.read_text())
    drifts = []

    prev_ports = {(s["port"], s["binding"]) for s in previous.get("exposed_services", [])}
    curr_ports = {(s["port"], s["binding"]) for s in current.get("exposed_services", [])}
    for port, binding in curr_ports - prev_ports:
        drifts.append({
            "type": "new_exposure",
            "port": port,
            "binding": binding,
            "severity": "HIGH"
        })

    for port, binding in prev_ports - curr_ports:
        drifts.append({
            "type": "port_removed",
            "port": port,
            "binding": binding,
            "severity": "MEDIUM"
        })

    baseline_file.write_text(json.dumps(current, ensure_ascii=False, indent=2))
    return drifts


def send_alert(title: str, body: str):
    """Send Telegram alert"""
    token = Path("/opt/net-discovery/telegram_token").read_text().strip() if Path("/opt/net-discovery/telegram_token").exists() else ""
    chat_id = Path("/opt/net-discovery/telegram_chat").read_text().strip() if Path("/opt/net-discovery/telegram_chat").exists() else ""
    if not token or not chat_id:
        return
    import requests
    url = f"https://api.telegram.org/bot{token}/sendMessage"
    requests.post(url, json={"chat_id": chat_id, "text": f"🔒 *{title}*\n\n{body}", "parse_mode": "Markdown"})


def main():
    print(f"[{datetime.now()}] Starting network topology analysis...")

    # 1. Collect data
    subprocess.run(["/opt/net-discovery/collect.sh"], check=True)

    # 2. LLM reasoning
    raw = read_all_data()
    prompt = build_prompt(raw)
    result = call_llm(prompt)

    if "error" in result:
        print(f"LLM analysis failed: {result['error']}")
        return

    # 3. Drift detection
    drifts = drift_detection(result)

    # 4. Generate report
    report = {
        "timestamp": datetime.now().isoformat(),
        "topology": result.get("topology", []),
        "exposed_services": result.get("exposed_services", []),
        "summary": result.get("summary", ""),
        "recommendations": result.get("recommendations", []),
        "drifts": drifts,
        "iptables_rules": result.get("iptables_rules", [])
    }

    report_file = DATA_DIR / f"report_{int(time.time())}.json"
    report_file.write_text(json.dumps(report, ensure_ascii=False, indent=2))
    print(f"Report saved: {report_file}")

    # 5. Print summary
    print(f"\n{'='*50}")
    print(f"Network Security Score Report")
    print(f"{'='*50}")
    print(f"Summary: {result.get('summary', 'N/A')}")
    print(f"\nExposed Services ({len(result.get('exposed_services', []))}):")
    for svc in result.get("exposed_services", []):
        emoji = {"HIGH": "🔴", "MEDIUM": "🟡", "LOW": "🟢"}.get(svc.get("risk", ""), "⚪")
        print(f"  {emoji} {svc['service']}: {svc['port']}/{svc.get('binding', '?')} [{svc['risk']}]")
        print(f"     Reason: {svc.get('reason', '')}")

    if drifts:
        print(f"\n⚠️ Detected {len(drifts)} configuration drift(s):")
        for d in drifts:
            print(f"  [{d['severity']}] {d['type']}: port {d.get('port', 'N/A')}")
    else:
        print("\n✅ No configuration drift — network state is stable")

    # 6. Send alert on high risk or drift
    high_risk = [s for s in result.get("exposed_services", []) if s.get("risk") == "HIGH"]
    if high_risk or drifts:
        alert_body = f"Found {len(high_risk)} high-risk exposed services, {len(drifts)} drift(s).\n\n"
        for s in high_risk:
            alert_body += f"- {s['service']}: {s['port']} ({s.get('reason', '')})\n"
        for d in drifts:
            alert_body += f"- Drift: {d['type']} port {d.get('port', 'N/A')}\n"
        send_alert("🔒 VPS Network Security Alert", alert_body)

    # 7. Generate Markdown report
    md_report = generate_markdown_report(report)
    report_md = DATA_DIR / f"report_{int(time.time())}.md"
    report_md.write_text(md_report)
    print(f"Markdown report: {report_md}")


def generate_markdown_report(report: dict) -> str:
    md = f"""# VPS Network Topology Analysis Report

**Generated**: {report['timestamp']}

## Security Summary

{report.get('summary', 'N/A')}

## Exposed Services

| Service | Port | Binding | Risk | Notes |
|---------|------|---------|------|-------|
"""
    for svc in report.get("exposed_services", []):
        md += f"| {svc['service']} | {svc['port']} | {svc.get('binding', '?')} | {svc.get('risk', '?')} | {svc.get('reason', '')} |\n"

    md += "\n## Service Dependency Topology\n\n```\n"
    for edge in report.get("topology", []):
        md += f"{edge['from']} --> {edge['to']} ({edge['protocol']}:{edge['port']})\n"
    md += "```\n"

    md += "\n## Configuration Drift\n\n"
    if report.get("drifts"):
        for d in report["drifts"]:
            md += f"- [{d['severity']}] {d['type']}\n"
    else:
        md += "- No drift, baseline stable\n"

    md += "\n## Recommended Actions\n\n"
    for i, rec in enumerate(report.get("recommendations", []), 1):
        md += f"{i}. {rec}\n"

    md += "\n## Suggested iptables Rules\n\n```bash\n"
    for r in report.get("iptables_rules", []):
        md += f"# {r.get('chain', 'INPUT')}\n{r['rule']}\n"
    md += "```\n"

    return md


if __name__ == "__main__":
    main()

chmod +x /opt/net-discovery/analyze.py
# Analyze every 30 minutes
(crontab -l 2>/dev/null; echo "*/30 * * * * /usr/bin/python3 /opt/net-discovery/analyze.py >> /var/log/net-discovery.log 2>&1") | crontab -

# View baseline history
ls -la /var/db/net-baseline/
cat /var/db/net-baseline/latest.json | python3 -m json.tool | head -50

vim /opt/net-discovery/harden.sh

#!/bin/bash
# Auto-generated by AI Network Analysis Engine — review before executing
set -euo pipefail

echo "🔒 Applying network hardening policies..."

# Default deny all inbound (unless explicitly allowed)
iptables -w -P INPUT DROP 2>/dev/null || true
iptables -w -P FORWARD DROP 2>/dev/null || true
iptables -w -P OUTPUT ACCEPT 2>/dev/null || true

# Allow loopback
iptables -w -A INPUT -i lo -j ACCEPT

# Allow established connections
iptables -w -A INPUT -m conntrack --ctstate ESTABLISHED,RELATED -j ACCEPT

# Allow SSH (consider restricting source IP in production)
# iptables -w -A INPUT -p tcp --dport 22 -s 0.0.0.0/0 -j ACCEPT

# Allow HTTP/HTTPS
iptables -w -A INPUT -p tcp --dport 80 -j ACCEPT
iptables -w -A INPUT -p tcp --dport 443 -j ACCEPT

# Allow ICMP (ping)
iptables -w -A INPUT -p icmp --icmp-type echo-request -j ACCEPT

# Drop broadcast
iptables -w -A INPUT -broadcast -j DROP

# Docker container network isolation reminder
if command -v docker &>/dev/null && docker ps &>/dev/null; then
    echo "💡 Tip: Use Docker custom bridge networks to prevent default bridge exposure"
fi

echo "✅ Basic hardening rules applied"
echo "📋 View rules: iptables -L -n -v"
echo "💾 Persist: iptables-save > /etc/iptables/rules.v4"

# Debian/Ubuntu
apt-get install -y iptables-persistent
iptables-save > /etc/iptables/rules.v4
ip6tables-save > /etc/iptables/rules.v6

# RHEL/CentOS
yum install -y iptables-services
service iptables save

vim /opt/net-discovery/render_topology.py

#!/usr/bin/env python3
"""Render LLM analysis results as a Mermaid topology diagram"""
import json
from pathlib import Path
from datetime import datetime

DATA_DIR = Path("/tmp/net-discovery")

def render_mermaid():
    report_files = sorted(DATA_DIR.glob("report_*.json"), reverse=True)
    if not report_files:
        print("No reports found")
        return

    latest = json.loads(report_files[0].read_text())

    mermaid = """```mermaid
graph TB
    subgraph External["🌐 External Network (0.0.0.0/0)"]
        INTERNET(["Internet"])
    end

    subgraph Host["🖥️ Host Machine"]
        SSH(["SSH :22"])
        WEB(["Web :80/:443"])
    end

    subgraph Containers["📦 Docker Containers"]
"""

    for svc in latest.get("exposed_services", []):
        risk_emoji = {"HIGH": "🔴", "MEDIUM": "🟡", "LOW": "🟢"}.get(svc.get("risk", ""), "⚪")
        safe_name = svc["service"].replace(" ", "_")
        mermaid += f'        {safe_name}(["{risk_emoji} {svc["service"]}\\n:{svc["port"]}"])\\n'

    mermaid += """    end

    INTERNET --> |"HTTP/HTTPS"| WEB
    INTERNET --> |"SSH"| SSH
"""

    for edge in latest.get("topology", []):
        from_safe = edge["from"].replace(" ", "_")
        to_safe = edge["to"].replace(" ", "_")
        mermaid += f'    {from_safe} -->|"{edge["protocol"]}:{edge["port"]}"| {to_safe}\\n'

    mermaid += "```\n"

    output = DATA_DIR / f"topology_{int(datetime.now().timestamp())}.md"
    output.write_text(mermaid)
    print(f"Mermaid topology saved: {output}")
    print("\n" + mermaid)

if __name__ == "__main__":
    render_mermaid()

vim /opt/net-discovery/docker_isolation.py

#!/usr/bin/env python3
"""Generate Docker network isolation recommendations based on LLM analysis"""
import json
import subprocess
from pathlib import Path

def generate_isolation_networks():
    """Generate recommended Docker network isolation configuration"""
    result = subprocess.run(
        ["docker", "ps", "--format", "{{.Names}}\t{{.Image}}\t{{.Ports}}"],
        capture_output=True, text=True
    )

    containers = {}
    for line in result.stdout.strip().split("\n"):
        parts = line.split("\t")
        if len(parts) >= 3:
            containers[parts[0]] = {"image": parts[1], "ports": parts[2]}

    networks = {
        "public": {"driver": "bridge", "description": "Externally exposed services"},
        "internal": {"driver": "bridge", "description": "Internal service communication"},
        "data": {"driver": "bridge", "description": "Database layer (internal access only)"},
    }

    print("Recommended Docker Network Isolation Scheme:\n")
    for name, config in networks.items():
        print(f"  Network: {name}")
        print(f"    Driver: {config['driver']}")
        print(f"    Purpose: {config['description']}")
        print()

    print("Assign containers to networks:")
    print("  public  → Nginx, API gateways, etc.")
    print("  internal → Business logic containers")
    print("  data    → PostgreSQL, Redis, MongoDB (no direct port exposure)")
    print()

    compose = """
# Recommended network isolation in docker-compose
networks:
  public:
    driver: bridge
  internal:
    driver: bridge
  data:
    driver: bridge
    internal: true  # No external network access
"""
    print(compose)

if __name__ == "__main__":
    generate_isolation_networks()

{
  "exposed_services": [
    {
      "service": "PostgreSQL",
      "port": 5432,
      "binding": "0.0.0.0",
      "risk": "HIGH",
      "reason": "Database port directly bound to 0.0.0.0 — any public IP can attempt connection"
    },
    {
      "service": "Redis",
      "port": 6379,
      "binding": "0.0.0.0",
      "risk": "HIGH",
      "reason": "Redis has no default authentication; public exposure is easily exploited by ransomware (e.g., RedisGremlin)"
    },
    {
      "service": "MinIO Console",
      "port": 9001,
      "binding": "0.0.0.0",
      "risk": "MEDIUM",
      "reason": "Admin panel exposed to public internet; requires password but should be internal-only"
    }
  ],
  "iptables_rules": [
    {
      "chain": "INPUT",
      "rule": "iptables -A INPUT -p tcp --dport 5432 -s 172.17.0.0/16 -j ACCEPT"
    },
    {
      "chain": "INPUT",
      "rule": "iptables -A INPUT -p tcp --dport 6379 -s 172.17.0.0/16 -j DROP"
    },
    {
      "chain": "INPUT",
      "rule": "iptables -A INPUT -p tcp --dport 9001 -s 127.0.0.1 -j ACCEPT"
    }
  ],
  "summary": "2 HIGH-risk exposed services detected (PostgreSQL and Redis bound to 0.0.0.0). Immediate restriction to Docker internal network access is recommended.",
  "recommendations": [
    "Change bind-address for PostgreSQL and Redis to 127.0.0.1 or Docker internal IP",
    "Set requirepass on Redis",
    "Access MinIO Console only through reverse proxy, not port 9001 directly",
    "Enable fail2ban for SSH protection"
  ]
}

# Immediately block high-risk ports
iptables -A INPUT -p tcp --dport 5432 -s 172.17.0.0/16 -j ACCEPT
iptables -A INPUT -p tcp --dport 5432 -j DROP

iptables -A INPUT -p tcp --dport 6379 -s 172.17.0.0/16 -j ACCEPT
iptables -A INPUT -p tcp --dport 6379 -j DROP

# Add Redis password
echo "requirepass $(openssl rand -base64 32)" >> /etc/redis/redis.conf
systemctl restart redis

# Persist rules
iptables-save > /etc/iptables/rules.v4
